"What's the Crack?" When cracking is observed in a building the most common reaction is that it must be the foundations and that it must be serious. Many surveyors are nervous about diagnosing cracks. This is understandable, as the interpretation of cracks can be difficult to teach, with university courses providing little or no time for field experience. Yet by understanding one straightforward principle the majority of cracks can be diagnosed in just a few minutes. Linking this with a good knowledge of construction techniques, the factors that distort cracking patterns and the key features of common causes of cracking, almost all cracks can be diagnosed quickly and with confidence. Practical Guide to Diagnosing Structural Movement in Buildings provides a methodology by which cracks and movement in buildings can be diagnosed. Written in four parts, part one describes the key principles of movement and cracking. Parts two and three describe the main features of common forms of movement and the associated crack patterns. Part two covers causes other than ground or foundation movement and part three covers movement caused by ground or foundation problems. Part four briefly describes the techniques used to arrest further movement or repair damage cause by movement. Primarily intended for the relatively inexperienced surveyor or engineer and undergraduate students of surveying as a practical guide for use on site, it focuses on identification and diagnosis. It will not only help in correctly diagnosing the problem but it will also demonstrate a methodical approach to show and record how the diagnosis was reached – critical when giving advice to third parties. "What's the crack?" - In the vast majority of cases it's not foundation related and in most cases it's not indicating a serious defect.

Table of Contents:
Introduction viii List of Figures xi Acknowledgements xvi PART 1 FIRST PRINCIPLES 1 1.1 First Principles 3 1.2 Crack Patterns and Cracks 8 1.3 Rotational Movement 9 1.4 Contra Rotational Movement 11 1.5 Weak Routes 14 1.6 Load Distribution 22 1.7 Movement and Orientation 26 1.8 Summary of First Principles and Process 28 PART 2 CRACKS IN BUILDINGS NOT RELATED TO FOUNDATIONS 31 2.1 Expansion Cracking 33 2.2 Cavity Wall Tie Corrosion 44 2.3 Corrosion of Metal Built into Walls 53 2.4 Vibration of Built in Fixings 57 2.5 Roof Spread 60 2.6 Springing from Deflected Beams 67 2.7 Lack of Lateral Stability 70 2.8 Lack of Lateral Stability in Modern Gable Walls 76 2.9 Overloaded Beams 79 2.10 Absence of Lintels (Beams) Over Openings in Cavity Walls 84 2.11 Overloaded Floors 91 2.12 Overloaded Walls 95 2.13 Differential Movement 99 2.14 Arch Thrust and Arch Flattening 101 2.15 Load Path Cracking 109 2.16 Bulging of Walls due to Decay of Bonding Timbers 112 2.17 Bulging and Separation in Solid Brick Walls 115 2.18 Separation of Rubble Filled Stone Walls 118 2.19 Floor Slab Settlement (Compaction) 120 2.20 Load Concentrations 127 2.21 Sulphate Attack 129 2.22 Concrete Block Shrinkage 134 2.23 Shrinkage of Calcium Silicate Bricks 138 PART 3 CRACKS IN BUILDINGS RELATED TO THE FOUNDATIONS AND GROUND MOVEMENT 141 3.1 Introduction 143 3.1.1 Design for Load 145 3.1.2 Design for Stability 147 3.1.3 Identifying Below Ground Defects 148 3.2 Foundation Movement Caused by Clay Shrinkage 151 3.3 Clay Heave 159 3.4 Seasonal Expansion of Clay Subsoil 162 3.5 Eccentric Loading on Foundations 164 3.6 Uneven Loading 167 3.7 Load Concentrations on Foundations 169 3.8 Differential Foundation Movement 171 3.9 Initial Settlement after Construction or Alterations 176 3.10 Leaking Drains and Water Discharge Near to Buildings 179 3.11 Drains and Drain Trenches 182 PART 4 REPAIR METHODS 185 4.1 Introduction 187 4.2 Re-pointing 189 4.3 Re-pointing with Epoxy Mortar 191 4.4 Stitching in Brickwork 192 4.5 Reinforcing Brick Mortar Joints 193 4.6 Tie Bars 195 4.7 Restraint Straps 198 4.8 Buttresses/Piers 200 4.9 Preventing Roof Spread 201 4.10 Underpinning 203 4.11 Expanding Foam Underpinning 207 4.12 Grouting 209 4.13 Root Barriers 211 Index 213
